AZUD PREMIER PC,
PC AS, CNL Y HCNL.
AZUD PREMIER is the new flat pressure compesating dripper bond-on in multi-seasonal pipes developed by AZUD based on four key elements:
- • DS Technology applied to the labyrinth.
- • SILITEC membrane.
- • ELIPSIS chamber.
- • H.E.X. protection system.
• ADVANTAGE
1- SILITEC membrane :
manufactured in LSR, has superior characteristics than the rest: high dimensional, physical, chemicals and mechanical accuracy, obtaining a uniform flow rate and high performance in the operation of the dripper; allows a higher pressure compensating range than others: unalterable performance along its lifespan.
2- ELIPSIS chamber :
Pressure-compensating chamber specially designed to be the perfect combination together with the membrane, obtaining an optimum performance for a higher working interval not only in the compensation pressures but also in the remaining of its lifespan.
3- H.E.X protection system :
Based on a three-dimensional paterned filter, with an effective filtering surface in the base of AZUD PREMIER LINE dripper and a two-stage filtration, guaranteeing the total protection of the labyrinth of the dripper.
• ASPECIFICATIONS
- Ø 16 (PC)
- Ø 20 (PC)
- Ø 16 (PC AS)
- Ø 20 (PC AS)
- Ø 16 (CNL)
- Ø 20 (CNL)
- Ø 16 (HCNL)
- Ø 20 (HCNL)
• Models
1L - 1.6L - 2L - 2.3L - 3L - 3.5L
• Nominal thickness
0.9 mm - 1 mm - 1.1 mm - 1.2 mm
• ADDITIONAL INFORMATION
Working of the emitters with DS technology:
- A main flow drives the water outside the emitters. Its circulation speed is very high, what allows evacuating the solids that the water carries in suspension.
- Many secondary flows generate a high turbulence, contributing a dynamic protection system, which warranties the effective elimination of the particles that there were inside the emitter.
